ABZ INNOVATION
L50
The most efficient EU-made agricultural spraying drone, designed for large-scale farming – featuring an easily interchangeable spraying and spreading system.
GENERAL
INformation
The ABZ Innovation L50 is a class-leading agricultural drone designed for large-scale field operations. Its unique smart battery technology delivers outstanding flight efficiency, enabling it to outperform even drones with larger tank capacities. Combined with advanced LiDAR technology and interchangeable spraying and spreading systems, the L50 offers exceptional versatility, precision, and productivity.
*For quotes, demos, or product info, email sales@abzinnovation.com
Key
Benefits
50 L
(≈ 13 gal)
sprayer tank capacity
70 L
(≈ 18.5 gal)
easily upgradable spreader
Maximum
efficiency in the field
Uncompromising
reliability
*The efficiency of spraying may vary depending on the circumstances.
Unique
advantages
CAPACITY AND PERFORMANCE
- Payload: 50 L (≈ 13 gal) spraying system
- Coverage: 24 ha/h (≈ 59 ac/h) maximum performance
- Versatility: 70 L (≈ 18.5 gal) seeder & spreader compatibility
- Light weight: 51.9 kg (≈ 114.4 lbs) (total weight with battery)
-
Max. Take-off mass: 108 kg
(≈ 238 lb)
APPLICATION TECHNOLOGY
- Technology: CDA rotating disc system
- Droplet Size: 60 – 1000 µm adjustable range
- Flow Rate: 16 L/min (≈ 4 gal/min) maximum flow
NAVIGATION AND SAFETY
- Obstacle Avoidance: 3D, LiDAR based (ABZ sense)
- Precision: Dual-RTK, centimeter-level accuracy
- Camera: FHD resolution, 0-180° vertical adjustment
OPERATIONS AND SECURITY
- Data Privacy: No data transmission to remote servers
- Battery charging: Approx. 20-minute rapid charging
2-in-1 design:
Compatible with the 70L Spreader System
Do not compromise! For the L50, the 50L spraying tank can be effortlessly replaced with the optional 70L Spreader tank. This spreading system is specifically designed for the precise and even distribution of seeds, feed, fertilizer, and deicing agents.
Spreader System Key Parameters & Features:
- Capacity: 70L Spreader System
- Supported materials: dry materials including seeds, feed, fertilizer, and deicing agents (granules between 0.5 – 6.0 mm in diameter)
- Spread width: up to 12 meters
Where and When
the L50 is the best choice
Where
-
Large arable fields
(300+ ha / ≈ 741 ac) - High-canopy crops
- Hard-to-reach or wet fields
- Hilly / terraced terrain
- Dense orchards & special plots
- Water-limited regions
When
- After rain – immediate intervention
- Short treatment windows
- Fast-response disease control
- Desiccation periods
- When tractors cannot enter the field
*The US data presented are estimated values. For accurate specifications, please refer to the datasheet indicated for each product.
The European-made
ABZ Innovation L50 Smart Battery is here!
- Advanced Li-ion technology: up to 35% higher capacity
- Active cooling & intelligent BMS during flight and charging
- Class-leading endurance: 15–20 minutes of active spraying & up to 4.1 ha/flight
- Ultra-fast recharge in just 20–25 minutes
- Maximum efficiency, minimal downtime
WHAT WE
Offer
Optimise your workflow
- Have a return of investment in few months
- Speed up your workflow
- Reduce operating costs up to 90%
- Secure reliable spare parts
up to 90%
Lower operating costs
Train to be an expert
- Train with the best pilots
- Solve problems fast
- Discover smart solutions
- Embrace the future
Learn the
Future
Choose quality
- Trust European engineering
- Choose ISO-certified quality
- Fly CE-approved
- Demand flight-tested drones
CE
Certification
Stay in the air
- Join the community
- Get live support
- Talk to our experts
- Fix it and keep the warranty
Talk to our
Experts
Drone
Library
GET YOUR
Accessories
70L Spreader System
70L Spreader SystemReplace the 50L spraying tank with the 70L Spreader System in one simple step, for precise and uniform distribution of seeds, feed, fertilizer and de-icing materials.
Read more →
L50 Smart Battery
ABZ Innovation L50 Smart BatteryAn exclusive, custom-engineered power source for the L50, setting a new standard in the agricultural drone industry with longer flight times and rapid charging.
Read more →
ABZ Smart Charger 6000
ABZ Smart Charger 6000Charges up to four drone batteries at once with three speed modes. Efficient, safe and user-friendly – keeps your drones ready for action.
Read more →
ABZ Innovation L50
Night Kit
Night KitEnables precise and effective spraying during the night and early morning, so you can take advantage of optimal weather conditions.
Read more →
FTS
Flight Termination SystemA crucial safety device that independently stops drone flights in emergencies, protecting both people and property during operations.
Read more →
Emlid RS3
Emlid Reach RS3Multi-band, multi-constellation GNSS with up to 60° tilt compensation, IP67 and MIL-STD-810H rated design and an 18-hour battery.
Read more →Why
Choose us
Certified Quality
CE, ISO, FCC certified
Low-cost, high-efficiency
drone operation
Professional
Support & Aftersales
Get in touch
Would you like to learn more about our solutions, request a quote, or have any questions about our demo? Simply fill out the form to send us an email. We will get back to you shortly.
